MICROMANIPULATOR 6100
MICROMANIPULATOR 6100
SPECIFICATIONS
PLATEN
Accepts 10 or more magnetic or vacuum based manipulators
1 in. (25.4 mm) thick honeycomb construction for maximum stability
Fine Lift Control
True planar vertical motion, convenient knob control
Resolution: 0.3 micron per degree revolution
Range: 0.5 in. (12.7 mm)
Fast Lift Control
Raises platen and microscope with adjustable microscope lift delay
Range: 1.35 in. (34.3 mm)
Three locking up positions
Resolution: 18:1 reduction (handle:platen)
X•Y STAGE
Stage Movement
Range of motion 6 in. x 6 in. (152 mm x 152 mm)
Movement and vacuum stage planarity permanently set
at factory
Theta rotation control full 360° with conveniently located
locking knob
Control knobs coaxial X-Y for single hand operation from
either side, located center front
Vacuum Stage
Standard 5 in. (127 mm) diameter with dual tweezer
slots
Gold plated brass for low contact resistance
Flatness t.0005 in. (t 12 microns)
Electrical isolation exceeds 5000 megohms at 500VDC
OPTIONAL SOCKET STAGE
Conversion time vacuum to socket and back to vacuum
stage less than 60 seconds
Accepts P.C. cards with ZIF sockets for probing packaged devices while operating
Locking handle for theta rotation control
MICROSCOPE AND POST
Vertical positioning +1.4 in. ( support)
Vertical motion 0 -1.35 in. (34.3 mm) by platen fast lift
handle or fine control knob with adjustable delay
X-Y translation: 1 in. x 1 in. (25.4 mm x 25.4 mm) with
convenient knob control
Factory planarized X-Y translation
Coarse/fine focus control
Microscope
B&L MicroZoom° with 2:1 zoom in body
3 long working distance objectives (2.25X, 8X, 25X)
Quadruple nosepiece accepts optional 50X objective
Trinocular head with camera port, 10X eyepieces
Coaxial illuminator with system mounted transformer and
infinite rheostat control
DIMENSIONS AND FINISH
Size
24 in. (61 cm) wide x 248 in. (61 cm) deep x 22 in. (56 cm)
high with optics
Finish
Grained black anodized aluminum for long life
Weight
150 lbs. (68 kg)
