WEB Technology Inc CENTRIFUGE SYSTEM 9000
The Series 9000 Centrifuge is
the result of WEB Technology’s
years of experience with constant
acceleration testing of
high-reliability semiconductor
devices. Safety, reliability and
serviceability are emphasized
in the design and construction
of this highly-productive system.

The proper combination
of drive rotors and fixturing will
allow any microelectronic
package to be tested per the
requirements of Mil Standard
883C, Method 2001, Test Condition
A-E and other equivalent specifications.
FEATURES:

• Microprocessor control.

• Proven quill-shaft spindle-

drive design.

• Shunt-wound DC motor,

which minimizes service

requirements, while greatly

prolonging brush life.

• Automatic belt-tensioning

and alignment mechanism,

which eliminates the need

for routine adjustments and

extends belt life.

• Sealed test enclosure designed

for safe containment

of any potential load separation.

• Cycle times of under three

minutes are achievable.

• Compatibility with existing

fixturing.

• Set-up configuration data

can be entered either manually

or pre-programmed

and retrieved from the CPU’s memory.

• Extensive sensor network monitors all critical operating

parameters.

• Large 4-line x 40-character LCD status display for continuous test cycle feedback.
